Details
The A&D Apollo GF-A Series is flexible and practical. They are ideal for use in industrial, laboratory, educational, and jewelry applications. All Apollo models are equipped with USB & RS232 ports for easy communication with your PC or printer. The Apollo balances feature Smart-SHS advanced technology increasing performance and productivity along with innovative solutions to meet demands in validation, compliance and protection.. They also come standard with power adapter, die cast aluminum housing, stainless steel platform, fast stabilization time, and much more.
| Capacity | 1620 g |
|---|---|
| Readability | 0.001 g |
| Repeatability (Standard Deviation) |
0.002 g | 1600 g 0.001 g | 1000 g |
| Linearity | ±0.003 g |
| Accuracy After External Calibration* | ±0.010 g | 1 kg |
| Stabilization Time | Approximately 1.5 seconds (approximately 0.8 seconds for 5 g) |
| Sensitivity Drift | ±2 ppm / °C (10°C to 30°C / 50°F to 86°F, when automatic self calibration is OFF) |
| Calibration | External; wt. g. 50 g, 100 g, (100 g interval), 1600 g |
| Display | Reverse backlit LCD, character height, 17.8 mm |
| Display Refresh Rate | 5 times/second, 10 times/second or 20 times/second |
| Units of Measure** | g (gram), oz (ounces), lb (pound), lb-oz (pound-ounce), ozt (troy ounce), ct (metric carat), mom (momme), dwt (pennyweight), gr (grain), pcs (counting mode), % (percent mode), SG (specific gravity), and a user-programmable unit. |
| Counting Mode | Minimum unit mass: 0.001 g Number of samples: 5, 10, 25, 50 or 100 pieces |
| Percent Mode | Minimum 100% reference mass: 0.100 g Minimum 100% display: 0.01%, 0.1%, 1% (depends on the reference mass stored) |
| Operating Environment | 5°C to 40°C / 41°F to 104°F, 85% RH or less (no condensation) |
| Power Supply / Consumption | AC adapter / approximately 30 VA |
| Communication Interface | RS-232C and USB standard |
| Weighing Pan Size | 128 mm x 128 mm (5" x 5") |
| External Dimensions (W x D x H) | 212 mm x 317 mm x 93 mm (8.3" x 12.5" x 3.7") |
| Net Weight | Approximately 5 kg (11 lb) |
* Under stable environment (no rapid temperature/humidity change, vibration, draft, magnetism, static, etc). The mass of the weight may vary with age.
**One additional unit from tael (Singapore/HK jewelry/Taiwan/China), tola or Newton can be added upon request.
