The PMA.HD is the ideal solution for Painters, shops, and labs where higher accuracy for smaller amounts is needed.
| Model | LAB1X2N1 | |
|---|---|---|
| Approvals | FM - IS CL I, DIV 1, GP C, D T4; CL I, Zone 1, AEx ib IIB T4 | |
| Weighing Capacity | 2,200 g | |
| Readability | 0.01 g | |
| Tare Range (subtractive) | -2,200 g | |
| Weighing Pan | ø 180 mm | |
| Housing (W x D x H) | 212 mm x 294 mm x 261 mm | |
| Net Weight | Approximately 2.1 kg | |
| External Calibration Weight | 1, 2 kg (Class F1 or better) | |
| Allowable Operating Temperature | 5°C - 40°C (41°F - 104°F) | |
| Dust and Water Protection Rating | IP40 (in accordance to EN60529/IEC60529) | |
| Power Supply | Via USB 2.0 or higher or power supply YEPS01-USB | |
| Input Voltage / Power Consumption | 5 VDC / 2 W | |
| Ex-link Converter | Energy limiting unit included | |
| Data Output | USB / Type B | |
| Format | 7-bit ASCII, 1 Start-bit, 1 or 2 Stop-bits | |
| Parity | Even, odd, no parity | |
| Transmission Rates | 1200 to 57,600 Bit/s | |
| Handshake Mode | Software, hardware, or none | |
| Internal Applications |
Integrated mixing module for one job Recalculation (correction of over-pours) Calculation by factor (0.25 - 5.0) Stand-alone recipe processing (absolute, additive) Dual range 0.05g (up to 999.95 g) Hardware test and communication symbol |
|
