MSI-4260M Port-A-Weigh Industrial Digital Crane Scale with 12V SLA battery, 500 lb x 0.2 lb, NTEP approved

Item #201951

Be the first to review this product

10%off

Availability: In stock

List Price: $5,260.00

Now: $4,734.00

You Save $526.00
Accessories
  • Battery assembly, 12 volt rechargeable, for MSI-4260, MSI-4300, MSI-9300/HT, MSI-6260CS (RLW-PN 150367 / MSI-PN D00559-0004) (PN 150367) SKU: 150367 $145.00
  • Universal battery charger, 115/230 VAC, 50/60 Hz (NA plug standard), for MSI-4260, MSI-4300, MSI-9300/HT, MSI-6260CS (RLW-PN 138006 / MSI-PN 502221-0001) (PN 138006) SKU: 138006 $345.00
  • Universal 115/230 VAC 50/60 Hz (NA plug standard) battery charger for MSI-8000/MSI-8000HD battery powered device (MSI PN 503486-0001) (PN 149549) SKU: 149549 $165.00
  • MSI-8000 RF remote display (RLW-PN 139381 / MSI-PN 503208-0001) (PN 139381) SKU: 139381 $1,415.00
  • MSI-8000HD ScaleCore RF remote display, AC powered (no A/D) (RLW-PN 153591) (PN 153591) SKU: 153591 $1,541.00
  • Universal crane scale transport cart (RLW-PN 159221) (PN 159221) SKU: 159221 $1,340.00
  • RF rugged remote control for MSI products equipped with XBEE radios, non-CE (RLW-PN 173014) (PN 173014) SKU: 173014 $355.00
  • LaserLight2 Scoreboard, 4" with ScaleCore RF and tilt bracket (RLW-PN 178004) (PN 178004) SKU: 178004 $2,535.00
  • LaserLight2 Scoreboard, 6" with ScaleCore RF and tilt bracket (RLW-PN 178006) (PN 178006) SKU: 178006 $3,005.00
  • MSI-8004HD Remote Display, AC, red/green, 85~264 VAC, 47~440 Hz, 120~370 VDC (RLW-PN 178281) (PN 178281) SKU: 178281 $2,120.00
  • MSI 10-point NIST traceable calibration report (RLW-PN MSI-CCI) (PN MSI-CCI) SKU: MSI-CCI $525.00
Overview

  • IP66 cast aluminum

  • Top lifting eye or shackle, bottom thrust bearing swivel hook

  • Five-digit, 1.75 in (44.5 mm) LCD with programmable brightness control

  • 12 volt rechargeable battery (115/230 VAC battery charger is included)

  • Meets or exceeds OSHA, ANSI, ASME and other safety design standards (5:1 Ultimate Safety Factor)

  • NTEP Certified configuration

MSI-4260M Port-A-Weigh Industrial Digital Crane Scale with 12V SLA battery, 500 lb x 0.2 lb, NTEP approved

Details

The MSI-4260M Port-A-Weigh crane scale has an established reputation as the industry standard in medium to heavy-capacity overhead weighing and duty-cycle needs. With a proven mechanical design and advanced electronics, the MSI-4260M is versatile, reliable, accurate and user friendly. The MSI-4260M is designed to meet or exceed requirements of applicable ASME, ANSI, OSHA safety standards.

Capacity x Resolution 500 lb x 0.2 lb (250 kg x 0.1 kg)
Accuracy ± 0.1% + 1d of applied load
Resolution

Max NTEP Approved Class III: 2,500 divisions

Max NTEP Approved Class IIIL: 5,000 divisions

Max Non-NTEP Approved: 10,000 divisions
Enclosure IP66 cast aluminum
Lifting Eye, Link & Hook Crosby or equal with 360° thrust-bearing swivel hook
Design Overload 200% safe / 500% ultimate
Functions

Power: Turns unit ON or OFF

Zero: Zeros applied load up to 100% of capacity (limited range in NTEP configuration)

Tare: Tares applied load and displays weight in Net mode

User: Programmable as test, total, unit, peak hold, net/gross, view total and print
Display Five-digit, 1.75" (44.5 mm) LCD with programmable brightness control
Displayable Units Pounds or kilograms selectable
Annunciators COZ, Battery Level, Net, Total, lb/kg, Stability, RF and Setpoint LEDs
Power 12 volt rechargeable battery (115/230 VAC battery charger is included)
Operating Time Up to 250 hours between charging with typical use, less with RF Modem option
Temperature Range

Certified: 14°F to 104°F (-10°C to 40°C)

Operating: -20°F to 122°F (-28°C to 50°C)
Auto-Off Mode Powers off after the scale is not used for the set time (in minutes) 15, 30, 45, 60 or OFF selectable
Auto Sleep Mode Powers down during non-use after the set time (in minutes) and powers up with weight change or any key press; 5, 15, 30 or OFF selectable
Service Counters Counts number of lifts over percentage of capacity and lifts over capacity
Calibration Digital (procedure initiated by calibration switch)
Filtering OFF, LO, HI-1, HI-2 selectable
Warranty One year limited
Approvals NTEP COC 19-122
