MSI-4260M Port-A-Weigh Industrial Digital Crane Scale, battery operated, 500 lb x 0.2 lb, NTEP approved

Item #201999

Be the first to review this product

10%off

Availability: In stock

List Price: $5,265.00

Now: $4,739.00

You Save $526.00
Accessories
  • Universal 115/230 VAC 50/60 Hz (NA plug standard) battery charger for MSI-8000/MSI-8000HD battery powered device (MSI PN 503486-0001) (PN 149549) SKU: 149549 $165.00
  • MSI-8000 RF remote display (RLW-PN 139381 / MSI-PN 503208-0001) (PN 139381) SKU: 139381 $1,415.00
  • MSI-8000HD ScaleCore RF remote display, AC powered (no A/D) (RLW-PN 153591) (PN 153591) SKU: 153591 $1,541.00
  • Universal crane scale transport cart (RLW-PN 159221) (PN 159221) SKU: 159221 $1,340.00
  • RF rugged remote control for MSI products equipped with XBEE radios, non-CE (RLW-PN 173014) (PN 173014) SKU: 173014 $355.00
  • LaserLight2 Scoreboard, 4" with ScaleCore RF and tilt bracket (RLW-PN 178004) (PN 178004) SKU: 178004 $2,535.00
  • LaserLight2 Scoreboard, 6" with ScaleCore RF and tilt bracket (RLW-PN 178006) (PN 178006) SKU: 178006 $3,005.00
  • MSI-8004HD Remote Display, AC, red/green, 85~264 VAC, 47~440 Hz, 120~370 VDC (RLW-PN 178281) (PN 178281) SKU: 178281 $2,120.00
  • MSI 10-point NIST traceable calibration report (RLW-PN MSI-CCI) (PN MSI-CCI) SKU: MSI-CCI $525.00
Overview

  • IP66 cast aluminum

  • Top lifting eye or shackle, bottom thrust bearing swivel hook

  • Five-digit, 1.75 in (44.5 mm) LCD with programmable brightness control

  • Battery operated, 6 "D" cell 1.5V alkaline batteries

  • Meets or exceeds OSHA, ANSI, ASME and other safety design standards (5:1 Ultimate Safety Factor)

  • NTEP Certified configuration

MSI-4260M Port-A-Weigh Industrial Digital Crane Scale, battery operated, 500 lb x 0.2 lb, NTEP approved

Details

The MSI-4260M Port-A-Weigh crane scale has an established reputation as the industry standard in medium to heavy-capacity overhead weighing and duty-cycle needs. With a proven mechanical design and advanced electronics, the MSI-4260M is versatile, reliable, accurate and user friendly. The MSI-4260M is designed to meet or exceed requirements of applicable ASME, ANSI, OSHA safety standards.

Capacity x Resolution 500 lb x 0.2 lb (250 kg x 0.1 kg)
Accuracy ± 0.1% + 1d of applied load
Resolution

Max NTEP Approved Class III: 2,500 divisions

Max NTEP Approved Class IIIL: 5,000 divisions

Max Non-NTEP Approved: 10,000 divisions
Enclosure IP66 cast aluminum
Lifting Eye, Link & Hook Crosby or equal with 360° thrust-bearing swivel hook
Design Overload 200% safe / 500% ultimate
Functions

Power: Turns unit ON or OFF

Zero: Zeros applied load up to 100% of capacity (limited range in NTEP configuration)

Tare: Tares applied load and displays weight in Net mode

User: Programmable as test, total, unit, peak hold, net/gross, view total and print
Display Five-digit, 1.75" (44.5 mm) LCD with programmable brightness control
Displayable Units Pounds or kilograms selectable
Annunciators COZ, Battery Level, Net, Total, lb/kg, Stability, RF and Setpoint LEDs
Power Battery operated, six "D" cell 1.5V alkaline batteries
Operating Time Up to 1000 hours of battery life with typical use, less with RF Modem option
Temperature Range

Certified: 14°F to 104°F (-10°C to 40°C)

Operating: -20°F to 122°F (-28°C to 50°C)
Auto-Off Mode Powers off after the scale is not used for the set time (in minutes) 15, 30, 45, 60 or OFF selectable
Auto Sleep Mode Powers down during non-use after the set time (in minutes) and powers up with weight change or any key press; 5, 15, 30 or OFF selectable
Service Counters Counts number of lifts over percentage of capacity and lifts over capacity
Calibration Digital (procedure initiated by calibration switch)
Filtering OFF, LO, HI-1, HI-2 selectable
Warranty One year limited
Approvals NTEP COC 19-122
