A&D GC Series GC-15K Counting Scale, 15 kg x 0.002 kg

Item #GC-15K

Be the first to review this product

25%off

Availability: In stock

List Price: $1,080.00

Now: $810.00

You Save $270.00
Free Shipping
on this product
Calibration Method

Calibration ensures Regulatory and Audit Compliance

  • No Calibration
  • ISO 9000 Calibration Certificate - Bench - $95.00
Accessories
  • Load cell extension cable, 2m, for GC Series (A&D-PN GC-08) (PN GC-08) SKU: GC-08 $80.00
  • Brackets for AD-8561 with cable, for GC Series (A&D-PN GC-14) (PN GC-14) SKU: GC-14 $140.00
  • Multi-interface 02; USB-A and USB-B for scanner and PC (A&D-PN AD-8561-MI02) (PN AD-8561-MI02) SKU: AD-8561-MI02 $320.00
  • Multi-interface 04; USB-A and terminal block for comparator relay (A&D-PN AD-8561-MI04) (PN AD-8561-MI04) SKU: AD-8561-MI04 $320.00
  • Multi-interface 05; USB-A and external base terminal block (A&D-PN AD-8561-MI05) (PN AD-8561-MI05) SKU: AD-8561-MI05 $320.00
Overview

  • Automatic Item Search (AIS) instantly finds desired piece weight

  • Internal memory stores up to 1000 items

  • Memory capacity extension using a MicroSD card

  • Choice of power sources: AC adapter (included) or mobile battery (not included) via USB

  • Expand applications with AD-8561 Multi-Interfaces (available separately)

  • Automatic Counting Accuracy Improvement (ACAI)

  • Password lock and key lock functions

  • WinCT-Counting (freeware) for easy management of item data

A&D GC Series GC-15K Counting Scale, 15 kg x 0.002 kg

Details

Count efficiently with 1000 item memory and WinCT-Count software, included. With the lower power design, you can run the GC with a USB, AC Adapter or with a battery pack for portable applications. Easily connect to an A&D balance for lower piece weights or hook up to an industrial base for larger parts.

Capacity x Readability 15 kg x 0.002 kg
Units of Measure kg (kilogram), g (gram), lb (pound), oz (ounce), ozt (troy ounce), and pcs (pieces)
Number of Samples 5, 10, 25, 50, 100, or an arbitrary number of pieces
Minimum Unit Weight*i 0.4 g / 0.02 g
Repeatability (standard deviation) 0.002 kg
Linearity ±0.002 kg
Stabilization Time Approximately 1 second (typical value with the response characteristics and stability detection conditions are both set to prioritize speed)
Sensitivity Drift ±20 ppm / °C (5 to 35 °C / 41 to 95 °F)
Operating Temperature 0°C to 40°C / 32°F to 104°F, 85% RH or lower (no condensation)
Display

Count: 7 segment reverse-backlit LCD, character height 22 mm

Weight: 7 segment reverse-backlit LCD, character height 12.5 mm

Unit Weight: 5 x 7 dot reverse-backlit LCD, character height 6.7 mm

Information: 128 x 64 dot OLED
Display Refresh Rate Approximately 10 times/second (for the count and weight displays)
Standard Interfaces RS-232C (D-Sub 9-pin), MicroSD card *ii slot, External switch input terminal
Power Supply AC adapter (provided as standard), USB port of another device, or off-the-shelf mobile battery *iii via USB cable (Type-A to Type-C, 1.5m)
Weighing Pan Size 300 mm x 210 mm (11.81" x 8.27")
Dimensions (W x D x H) 315 mm x 355 mm x 121 mm (12.4" x 13.98" x 4.76")
Weight Approximately 4.9 kg (10.8 lb)
Materials

Display unit: ABS + polyester film

Base unit: Die-cast aluminum + ABS

Weighing pan: SUS430

*i Selectable by internal setting

*ii Card type: SDHC. File system: FAT32. Operation is not guaranteed for all MicroSD cards (A&D verified operation with Panasonic's RP-SMGA04GJK 4 GB).

*iii Operation is not guaranteed with other AC adapters, USB ports of all devices, or all mobile batteries.
